Ubiquiti UniFi U7 Pro Max Access Point – WiFi 7 Ceiling-Mounted 6 GHz AP with 8 Spatial Streams

The Ubiquiti UniFi U7 Pro Max is a high-performance, ceiling-mounted WiFi 7 access point engineered for large-scale, high-demand environments. With support for 6 GHz frequency, eight spatial streams, and real-time spectral scanning, it delivers interference-free, ultra-fast connectivity. Designed for enterprises, campuses, hospitality, and high-density venues, the U7 Pro Max offers expansive coverage, high client capacity, and advanced management features through the UniFi Network platform.

Product Features

WiFi 7 with 6 GHz Support

Next-generation WiFi 7 technology ensures faster speeds, reduced latency, and better efficiency, including support for the 6 GHz band for congestion-free wireless performance.

Eight Spatial Streams for Maximum Throughput

Advanced MIMO capabilities deliver outstanding throughput across all supported bands, ensuring reliable connectivity for hundreds of devices simultaneously.

Real-Time Spectral Analysis

Dedicated spectral scanning optimizes channel selection and minimizes interference for stable, high-quality wireless performance.

Expansive Coverage and High Capacity

Covers up to 160 m² (1,750 ft²) and supports over 500 connected clients, making it ideal for enterprise networks, event spaces, and educational facilities.

High-Speed 2.5 GbE Uplink

Equipped with a 2.5 GbE RJ45 uplink, ensuring faster backhaul speeds to accommodate high-bandwidth applications.

Flexible PoE+ Powering

Powered via PoE+ for convenient ceiling or wall installation without separate power cabling.

Enterprise-Grade Security and Management

Supports WPA3, guest traffic isolation, VLAN tagging, and per-user rate limiting, with centralized configuration through UniFi Network software.

Product Specifications

• WiFi Standards: 802.11a/b/g/n/ac/ax/be
• Bands: 2.4 GHz / 5 GHz / 6 GHz
• Spatial Streams: 2×2 (2.4 GHz & 6 GHz), 4×4 (5 GHz)
• Max TX Power: 23 dBm (2.4 GHz), 29 dBm (5 GHz), 23 dBm (6 GHz)
• Throughput: 688 Mbps (2.4 GHz), 8648 Mbps (5 GHz), 5765 Mbps (6 GHz)
• Coverage Area: 160 m² (1,750 ft²)
• Max Clients: 500+
• Antenna Gain: 4 dBi (2.4 GHz), 6 dBi (5 GHz), 5.9 dBi (6 GHz)
• Networking Interface: 1× 1/2.5 GbE RJ45
• Power Method: PoE+ (44–57V DC)
• Max Power Consumption: 22W
• Mounting Options: Ceiling, wall (hardware included)
• Dimensions: 206 × 46 mm
• Weight: 680 g
• Enclosure Material: Polycarbonate, aluminum
• Operating Temperature: -30 to 60°C
• Humidity: 5–95% non-condensing
• Certifications: CE, FCC, IC

Applications

• Enterprise Networks – High-capacity wireless for offices and corporate campuses
• Educational Institutions – Reliable coverage for classrooms, lecture halls, and libraries
• Hospitality & Event Venues – Seamless guest connectivity in hotels, convention centers, and stadiums
• Healthcare Facilities – Secure and interference-free connectivity for medical devices and staff
• Retail and Commercial Spaces – Fast, stable WiFi for POS systems, staff devices, and customer access
