TP-Link Archer C7 AC1750 Dual-Band Gigabit Wireless Router

The TP-Link Archer C7 AC1750 is a high-performance dual-band Wi-Fi router built for seamless HD streaming, lag-free online gaming, and fast web browsing. Delivering combined wireless speeds up to 1750 Mbps—1300 Mbps on the 5 GHz band and 450 Mbps on the 2.4 GHz band—it provides the bandwidth needed for demanding applications. With three external antennas, full Gigabit Ethernet ports, USB file sharing capabilities, and OneMesh support, the Archer C7 offers stable and wide-reaching wireless coverage for medium to large homes. It supports the latest Wi-Fi 5 (802.11ac) standard and includes advanced features like VPN server, parental controls, and guest networks for flexible, secure connectivity.

Product Features

Fast dual-band Wi-Fi performance

Supports simultaneous 2.4 GHz and 5 GHz connections with a total combined speed of 1750 Mbps, ideal for HD video streaming and online gaming.

USB file sharing and media server

Includes a USB 2.0 port to easily share printers, files, or media within your network or remotely via an FTP server.

Strong coverage with high-gain antennas

Three external high-performance antennas ensure stable Wi-Fi coverage throughout 3-bedroom homes, forming a reliable, far-reaching wireless network.

Full Gigabit wired connectivity

Features one Gigabit WAN port and four Gigabit LAN ports for fast, stable wired connections to devices like smart TVs, desktops, and gaming consoles.

OneMesh compatibility

Works with TP-Link OneMesh products to build a seamless whole-home mesh network without replacing existing devices.

Secure guest access

Allows the creation of isolated 2.4 GHz and 5 GHz guest networks to ensure secure internet access for visitors without exposing the main network.

Advanced security and parental controls

Includes WPA/WPA2 encryption, SPI firewall, IP and MAC binding, and robust parental controls like URL filtering and time-based access.

Built-in VPN support

Supports OpenVPN and PPTP servers for secure remote access to your home network.

Easy setup and app-based management

Quickly set up and manage the router using the TP-Link Tether mobile app or web-based interface with firmware updates via the cloud.

Product Specifications

• Wi-Fi standard: Wi-Fi 5 (IEEE 802.11ac/n/a 5 GHz; IEEE 802.11n/b/g 2.4 GHz)
• Wireless speeds: 1300 Mbps on 5 GHz; 450 Mbps on 2.4 GHz
• Wi-Fi range: Suitable for 3-bedroom houses
• Antennas: 3× external fixed high-performance antennas
• Wi-Fi capacity: Medium (dual-band with optimized device distribution)
• Operating modes: Router mode, Access Point mode
• Processor: Qualcomm CPU
• Ethernet ports: 1× Gigabit WAN, 4× Gigabit LAN
• USB support: 1× USB 2.0 port (NTFS, FAT32)
  • Functions: FTP server, media server, Samba server
• Buttons: Wi-Fi On/Off, Power On/Off, WPS/Reset
• Power supply: 12 V ⎓ 1.5 A
• Wi-Fi encryption: WPA, WPA2, WPA/WPA2-Enterprise (802.1x)
• Network security: SPI firewall, access control, IP & MAC binding, application layer gateway
• Guest network: 1× 2.4 GHz and 1× 5 GHz guest network
• VPN support: OpenVPN, PPTP
• Protocols: IPv4, IPv6
• OneMesh: Supported
• Parental controls: URL filtering, time controls
• WAN types: Dynamic IP, Static IP, PPPoE, PPTP, L2TP
• Quality of service: QoS by device
• NAT forwarding: Port forwarding, port triggering, DMZ, UPnP
• IPTV support: IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN
• DHCP: DHCP server, address reservation, client list
• DDNS support: TP-Link, DynDNS, NO-IP
• Cloud services: TP-Link ID, OTA firmware upgrades
• Management: TP-Link Tether app, web interface
• Dimensions: 243 × 160.6 × 32.5 mm
• Operating temperature: 0℃ to 40℃ (32℉ to 104℉)
• Storage temperature: -40℃ to 70℃ (-40℉ to 158℉)
• Operating humidity: 10% to 90% non-condensing
• Storage humidity: 5% to 90% non-condensing
• Certifications: FCC, CE, RoHS
