Programmable Keys |
53 Keys |
|
|
Numeric Keypad |
Excluded from the count of programmable keys |
|
|
Alphanumeric Keys |
N/A |
|
|
Control-Key Structure |
6 Positions (L0, L1, L2, L3, L4, LP) Key is extractable at positions L0 & L1 |
|
|
Control-Key Function |
Programmable answer-back capability, page-select (5) functions, and security lock |
|
|
Codes Programmable |
ASCII or SCAN CODE |
|
|
Capacity Per Key |
1 to 255 characters per key |
|
|
Versatile Programmability |
Up to 8 multi-shift levels per key, per page |
|
|
Memory |
Non-Volatile 8KB |
|
|
Magnetic Stripe Reader |
Optional 2 Track, 3 Track, or JIS |
|
|
OS Supported |
MS-DOS, WIN ‘9x / NT / 2000 |
|
|
Languages Supported |
English |
|
|
Power Source |
5V DC / 150mA max. (Standard 200mA max. w/ MSR) |
|
|
Interface |
Standard PC AT keyboard protocol 5-pin DIN AT Connector 6-pin mini-DIN PS/2 connector |
|
|
Key Switches |
MTBF: Minimum 15 million operations per key |
|
|
Data Memory |
100 years of data retention |
|
|
Dimensions |
364mm(W) x 210mm(D) x 51mm(H) 10.33″ x 8.26″ x 2.00″ |
|
|
Weight |
2.36kg (5.20 lbs) |
|
|
Applicable Conformity |
CE, FCC Class A |
