Magnizon HG6048SW-LCD 6KVA/4.8KW Pure Sinewave Inverter with 40A Built-in Battery Charger

6KVA / 4.8KW continuous output power
Pure sine wave output for smooth, reliable power
Wide input voltage range: 153V – 267V AC
Built-in 40A battery charger with 3-stage charging
High efficiency (>95%) for minimal energy loss
Smart charging system for optimized battery health
LCD display for real-time status monitoring
Overload, short-circuit, and over-temperature protection
Auto-restart feature during AC recovery
Compatible with multiple battery types (Lead Acid, AGM, GEL)
Surge power capacity: 10KVA
Rack-mount and wall-mount installation options
CE, RoHS certified for safety and compliance
Quiet operation with low idle current
Operating temperature: 0°C to 40°C

Original price was: KSh 120,000.00.Current price is: KSh 102,000.00.

Magnizon HG6048SW-LCD 6KVA/4.8KW Pure Sinewave Inverter with 40A Built-in Battery Charger | Reliable Power Solution for Homes & Businesses

The Magnizon HG6048SW-LCD is a high-performance 6KVA/4.8KW pure sinewave inverter designed to provide stable power for both residential and commercial applications. Offering 48V DC input and 230VAC output, this advanced inverter is engineered to deliver clean, efficient power, ensuring the smooth operation of sensitive equipment such as computers, televisions, and medical devices. With a built-in 40Amp battery charger and automatic voltage regulation, the HG6048SW-LCD offers seamless integration with solar power systems and grid power, making it the perfect choice for off-grid and hybrid power solutions.

Product Features

High-Power Capacity (6KVA / 4.8KW) The Magnizon HG6048SW-LCD boasts an impressive 6KVA continuous output, providing 4.8KW of reliable power to support various household and commercial devices. Whether it’s a refrigerator, air conditioner, lighting, or computing systems, this inverter offers high surge power and stable output. Pure Sinewave Output for Sensitive Devices This inverter provides pure sinewave output, ensuring that even the most sensitive devices run efficiently and without distortion. Sensitive electronics such as TVs, computers, medical equipment, and audio systems are protected from electrical interference and voltage fluctuations. Built-in 40A Smart Battery Charger With an integrated 40A smart battery charger, the HG6048SW-LCD ensures that your battery bank is charged safely and efficiently. This feature is critical for maintaining optimal battery life and ensuring that power is always available when needed. Wide Input Voltage Range (153V-267V) The wide input voltage range of 153V to 267V ensures that the inverter can handle fluctuations in grid power and continues to provide reliable performance. It adjusts seamlessly to the input conditions, delivering consistent and stable power to connected devices. Intelligent LCD Display The intelligent LCD display provides real-time information on system status, including input voltage, battery charge levels, and load capacity. The display also shows error codes for quick troubleshooting and maintenance, simplifying the monitoring of system performance. Efficient Battery Management The advanced 3-stage charging system (Bulk, Absorption, and Float) helps in efficient battery charging and prevents overcharging. The intelligent battery management system monitors voltage levels, ensuring that batteries are charged optimally to extend their lifespan. Auto Restart Function The auto restart feature ensures that the inverter automatically restarts when AC power is restored after a power outage. This ensures uninterrupted power during power recovery, providing added convenience for critical applications. Multiple Protection Mechanisms The HG6048SW-LCD is equipped with overload protection, over-temperature protection, short-circuit protection, and battery deep discharge protection, safeguarding your system and connected appliances from potential damage.

Product Specifications

Input AC

Nominal Input Voltage: 230V AC
Input Voltage Range: 153V AC – 267V AC
Frequency: 50Hz
Low Voltage Alarm: 153V AC
High Voltage Alarm: 267V AC
Efficiency: >97%

Output

Rated Output Power: 6KVA / 4.8KW
Surge Power: 9KVA (Maximum)
Output Voltage: 230V AC ± 5%
Output Waveform: Pure Sinewave
Output Frequency: 50Hz
Overload Protection: Yes
Surge Protection: Yes
Efficiency: >90%

DC Input

Nominal DC Input Voltage: 48V DC
Voltage Range: 44V DC – 58V DC
No Load Power Consumption: <10W
Standby Power Consumption: <5W
Low Battery Voltage Cut-off: 44V DC
High Voltage Cut-off: 58V DC
Efficiency: >90%

Battery Charger

Built-in Charger: 40A Smart Battery Charger
Charging Algorithm: 3-Stage (Bulk, Absorption, Float)
Max Charging Current: 40A
Overcharge Protection: Yes
Battery Types: VRLA, Gel, AGM, and other types of batteries
Charging Voltage Range: 44V – 58V DC
Battery Voltage: 48V DC

Display Indicators

LCD Display: Displays input voltage, output voltage, load level, battery charge status, and fault indicators
Fault Indicators: Shows error codes for quick troubleshooting
Battery Status: Displays battery charge levels and alarms

General Specifications

Dimensions (WxHxD): 500 x 260 x 160 mm
Net Weight: 11.5 kg
Operating Temperature: 0°C to 50°C
Storage Temperature: -15°C to 60°C
Humidity: 5% to 95% (non-condensing)
Noise Level: <55 dB
Quality/Safety Standards: ISO9001:2015, ISO14001:2015, CE, RoHS

Warranty

Warranty: 18 months limited warranty

Applications

Residential & Commercial Use: Provides reliable power for homes, offices, and small businesses.
Hybrid Solar Power Systems: Perfect for integrating with solar panels, offering both solar energy and grid backup.
Off-Grid Systems: Ideal for remote locations and off-grid applications, where reliable power is essential.
Backup Power for Critical Equipment: Keeps essential appliances such as refrigerators, medical devices, and computers running during power outages.
Remote Telecom & Data Centers: Provides uninterrupted power for telecom equipment, server rooms, and data centers.
