Hikvision DS-TVL221-1-6D Entrance & Exit Signal Light

The Hikvision DS-TVL221-1-6D Entrance & Exit Signal Light is a high-visibility LED traffic indicator designed to manage vehicle flow at access points such as parking lots, toll booths, gated communities, and commercial facilities. With its bright red and green LED signals, the unit ensures clear traffic direction, enhancing safety and operational efficiency. Engineered for both indoor and outdoor use, the DS-TVL221-1-6D features a weather-resistant housing, energy-efficient design, and seamless compatibility with Hikvision access control and parking systems, making it a reliable solution for smart traffic management.

Product Features

Bright LED Indicators for Clear Traffic Guidance

Equipped with high-intensity red and green LEDs, the signal light delivers highly visible indicators to guide vehicles effectively. Its high luminance ensures visibility from up to 100 meters, reducing driver confusion and improving traffic safety.

Seamless Integration with Access Control Systems

The DS-TVL221-1-6D integrates effortlessly with Hikvision parking systems, barrier gates, and access control platforms. This enables real-time synchronization for automated entry/exit control, ensuring smooth and secure traffic coordination.

Durable and Weather-Resistant Build

Constructed from high-quality PC material and designed with an IP-rated enclosure, this signal light offers strong resistance against dust, rain, and environmental stress. It performs reliably in various climates, including outdoor deployments.

Energy-Efficient and Long-Lasting LEDs

Using low-power, high-efficiency LED modules, the unit minimizes energy consumption while offering a lifespan of over 50,000 hours. This makes it a cost-effective and maintenance-friendly solution for long-term installations.

Flexible Mounting and Easy Installation

Designed for ease of deployment, the signal light can be mounted on walls, poles, or integrated into existing access systems. Its compact structure and lightweight form factor simplify installation in diverse locations.

Enhanced Safety and Traffic Flow Management

By providing clear visual signals, the device reduces risks of collisions or unauthorized entry. It supports orderly vehicle movement, especially in high-traffic or time-sensitive environments such as business parks and residential complexes.

Product Specifications

• Color Display: Red and Green
• Best Viewing Distance: 1–100 meters
• Number of Modules: 2
• Control Mode: Control Card
• Luminance: ≥ 4000 cd/㎡
• LED Lamp Beads: Red – 40, Green – 40
• Working Temperature: -20 °C to 50 °C
• Humidity: ≤ 90% (non-condensing)
• Working Voltage: 100 to 240 VAC
• Power Consumption: Max. 7 W
• Lifespan: ≥ 50,000 hours
• Material: PC
• Color: Black
• Dimensions: 300 mm × 150 mm × 85 mm
• Weight: 1.4 kg
• Weight with Package: 2.3 kg
• Package Size: 420 mm × 195 mm × 205 mm
