Hikvision DS-TMT202-D Exit Ticket Station

The Hikvision DS-TMT202-D Exit Ticket Station is a smart and automated solution designed to manage vehicle exits efficiently in parking areas, toll stations, gated communities, and commercial facilities. This advanced system supports secure ticket validation through barcode and QR code scanning and integrates seamlessly with Hikvision’s broader parking and access control ecosystem. With its user-friendly interface, durable construction, and advanced connectivity, the DS-TMT202-D ensures a smooth, fast, and secure exit process, even in high-traffic environments.

Product Features

Fast and Secure Ticket Validation

Equipped with advanced barcode and QR code scanning technology, the DS-TMT202-D validates exit tickets quickly and accurately, minimizing delays and enhancing user convenience.

Seamless Integration with Parking and Access Systems

Designed to integrate effortlessly with Hikvision parking management platforms and access control systems, the station enables synchronized ticket validation, vehicle tracking, and secure data communication.

User-Friendly Interface with Clear Display

A 10.1-inch full HD LCD screen provides a clear, intuitive interface that guides users through the exit process, reducing the need for staff intervention and improving the overall user experience.

Automated and Remote Monitoring Capabilities

Supports centralized management and remote monitoring via TCP/IP protocol, allowing operators to oversee multiple units, perform remote diagnostics, and manage system settings in real time.

Weather-Resistant and Durable Build

Constructed with high-quality, weatherproof materials, the unit withstands extreme temperatures and humidity, making it suitable for both indoor and outdoor installations.

Supports Multiple Exit Methods

The station supports QR code/barcode scanning, IC/CPU card reading, and manual validation, offering flexibility for prepaid systems, automated payments, or staff-assisted exits.

Efficient Traffic Flow Management

By automating the exit ticket validation process, the DS-TMT202-D significantly reduces vehicle congestion and speeds up the flow of traffic at exit points.

Product Specifications

• Audio Encoding: 4 Kbps
• Audio Input: All-directional microphone
• Audio Output: 5.5W loudspeaker
• Audio Quality: Echo suppression, noise cancellation
• Two-Way Audio: Full duplex intercom
• Protocol: TCP/IP
• Network Interface: 10M/100M self-adaptive × 1
• Recognition Distance: 0–9 cm
• Recognition Types: Barcode, QR code
• Type: 10.1 inch LCD screen
• Resolution: 1080P
• Alarm Input: 2
• Alarm Output: 2
• Type: IC card, CPU card
• Frequency: 13.56 MHz
• Operating System: Embedded Linux
• Working Temperature: -40°C to 70°C
• Working Humidity: 10% to 95%
• Power Supply: 220V 50Hz
• Power Consumption: <50W
• Dimensions: 230 × 237.5 × 1386 mm
• Weight: 16.86 kg
• Dimensions (with Package): 320 × 360 × 1492 mm
• Weight (with Package): 19.51 kg
