D-Link DGS-1016D/B 16-Port Gigabit Unmanaged Ethernet Switch

The D-Link DGS-1016D/B is a 16-port unmanaged Gigabit switch designed to deliver high-speed networking with effortless deployment. Built with D-Link’s Green Technology, this switch automatically adjusts power consumption based on port activity and cable length, resulting in reduced operational costs without compromising performance. With its plug-and-play functionality, silent fanless operation, and durable metal chassis, the DGS-1016D/B is the ideal networking solution for small to medium-sized businesses seeking dependable and energy-efficient performance.

Product Features

16 High-Speed Gigabit Ports

Equipped with sixteen 10/100/1000 Mbps ports, the DGS-1016D/B allows seamless wired connections for desktop computers, printers, storage devices, IP cameras, and other network hardware, providing full duplex speeds of up to 2000 Mbps per port.

Energy Efficient Green Technology

This switch supports IEEE 802.3az Energy-Efficient Ethernet, allowing it to automatically power down inactive ports and adjust power usage based on cable length, significantly reducing energy consumption and heat generation.

Plug-and-Play Simplicity

No configuration is required. The DGS-1016D/B is ready to use out of the box, making it ideal for environments where quick deployment and minimal IT intervention are important.

Fanless Silent Operation

The fanless design ensures silent operation, making it well-suited for offices, classrooms, and other quiet settings while also increasing overall reliability by eliminating moving parts.

Enhanced QoS Support

With IEEE 802.1p Quality of Service, the switch prioritizes time-sensitive data such as VoIP and streaming media to ensure optimal performance for critical applications.

Integrated Cable Diagnostics

The switch features a built-in cable diagnostic tool that uses front-panel LEDs to help identify cable faults, such as open or short circuits, allowing for fast troubleshooting.

Rugged Metal Housing

The solid metal chassis provides enhanced durability and aids in heat dissipation, making the DGS-1016D/B suitable for desktop placement or mounting in network racks.

Product Specifications

• Model: DGS-1016D/B
• Ports: 16 x 10/100/1000 Mbps Gigabit Ethernet (RJ-45)
• Switching capacity: 32 Gbps
• Forwarding method: Store-and-forward
• MAC address table: 8,000 entries
• Energy saving: IEEE 802.3az Energy-Efficient Ethernet
• QoS support: IEEE 802.1p
• Cable diagnostics: Yes
• Auto MDI/MDIX: Yes, all ports
• Jumbo frame support: Up to 9,216 bytes
• Power input: External power adapter
• Power consumption: 13.3 watts (maximum)
• Heat dissipation: 45.38 BTU/hr
• Operating temperature: 0°C to 40°C
• Storage temperature: -10°C to 70°C
• Operating humidity: 10% to 90% non-condensing
• Storage humidity: 5% to 90% non-condensing
• Dimensions: 280 mm x 125.8 mm x 44 mm
• Weight: 1.24 kg
• Mounting: Desktop or rackmount (mounting kit included)
• Chassis: Metal
• Fanless: Yes
• Certifications: CE, FCC Class B, RoHS
